Industrial High-Capacity Rotary Molding Line for Ice Cream Sticks | Global OEM ODM Manufacturer & Wholesale Supplier of Food Processing Equipment
- Model
- OEM ODM
Item specifics
- Production Capacity
- 500 to 500,000+ units/hour
- Motor Power
- 2.2kW to 11.25kW
- Precision Tolerance
- ±0.1mm to ±0.5mm
- Machine Weight
- ~150 kg to 2,500+ kg
- Dimension (L×W×H)
- 2.2×1.9×1.3 m for a rotary cutting machine
- Raw Material
- Primarily processes wood, with birch being a commonly specified example for its uniform, tasteless
- Automation Level
- Ranges from semi-automatic for basic models to fully automatic with PLC control systems
- Customization
- Many machines allow you to adjust molds, blade positions
- Hygiene & Safety
- Food-grade construction materials
Review
Description
Industrial High-Capacity Rotary Molding Line for Ice Cream Sticks | Global OEM ODM Manufacturer & Wholesale Supplier of Food Processing Equipment
Product Overview and Specifications
This fully automatic wooden ice cream stick production line is an integrated manufacturing system engineered to transform raw wood logs into high-quality, food-grade finished sticks with minimal manual intervention. The line is designed for industrial-scale production of ice cream sticks, popsicle sticks, coffee stirrers, tongue depressors, and similar wooden products.
Built with advanced CNC servo-driven technology, the system ensures high output, tight dimensional tolerances (±0.1mm), and consistent product quality. The entire process—from log preparation to final bundling—is automated, reducing labor costs and increasing efficiency.
| Stage | Equipment | Specifications |
| 1. Raw Material Preparation | Log Cutting Machine | Cuts full-length logs into uniform short segments |
| 2. Veneer Rotary Peeling | CNC Rotary Cutting Machine | Processing Diameter: 45mm–800mm; Spindle Speed: 280 RPM; Cutting Thickness: 0.3mm–6.5mm; Accuracy: ±0.05mm–±0.1mm; Power: 22.7 KW (380V, 50Hz); Capacity: 2–2.5 m³/hour; Weight: 2000–2250 KG; Dimensions: 2500×2400×1300mm |
| 3. Stick Forming | CNC Carved Cutting Machine | Finished Sizes: 114mm, 93mm (adjustable via blade change); Interchangeable carved cutting blades |
4. Drying & Initial Polishing | Steam Boiler + Polisher (PG-6-L3) + Heat Exchanger (HX-5) + Draft Fan (DF-15) | Target Moisture Content: 8%–12%; Removes moisture and provides initial surface polishing |
5. Chamfering | Chamfering Machine (e.g., MQ-01SX) | Rounds both ends; removes burrs; ensures food-contact safety |
6. Dust Removal & Polishing | Dust Removing & Polishing Machine | Eliminates residual dust; refines surface smoothness |
7. Visual Inspection | Visual Inspection Machine | Accuracy: Up to 97%; Speed: 45,000–55,000 pcs/hour; Four-camera system for detecting surface defects |
8. Bundling | Automatic Bundling Machine | Bundle Size: 50 pcs/bundle; Automatic counting and bundling |
9. Overall Line Performance | Full Automatic Line with PLC Control | Daily Output: 300,000–500,000 pcs; Tolerance: ±0.1mm; Moisture: 8%–12%; Power: 380V/440V, 50/60Hz, 3-phase; Certification: CE; Warranty: 1 year on core components |
10. Auxiliary Equipment | Blade Sharpening Machines | Maintains and sharpens rotary blades and carved cutting dies |
Key Advantages
1. High Precision – CNC servo-driven technology ensures uniform veneer thickness and clean cuts with ±0.1mm tolerance
2. Versatility – Machine can produce various sizes and shapes by changing carved cutting blades; also suitable for coffee stirrers, tongue depressors, and matchsticks
3. Material Efficiency – Can utilize leftover materials from furniture factories and wood crafts factories
4. Multi-stage Quality Control – Combines mechanical selection with four-camera visual inspection system for layered defect detection
5. Food Safety Compliant – Produces smooth, splinter-free sticks with rounded edges that meet food-contact standards
After-Sales Support
Installation Guidance: Engineers available to guide installation at customer's location
Training: Personnel training provided until qualified products are made
Warranty: 3-month guarantee on core components; lifelong repair service available
Customization: Machines can be tailored to specific production capacity and budget requirements
