Model
829736

Review

Description

   Product Description

Thrust Roller Bearing 829736

Specification

Design Units

Metric

Structure

Roller Bearing

Weights

20.27kgs

Cage Material

Steel Cage.Brass Cage.Nylon Cage

Material

Stainless Steel GCR15

Ball Type

Steel Roller

Seals Type

Open

Certificate

ISO9001:2008

Feature

This bearing with planar shaft washers

Number of Rows

Double

Dimensions

d-Bore Diameter

180mm

D-Outer Diameter

280mm

Precision Rating

P0 P5 P4 P6 P2

Clearance



                                                             C2 C3 C4 C5 C0

H-Total Width

90mm





Application

Double Direction Taper Thrust Roller Bearings can be used in many areas.



Double Direction Thrust Roller Bearing is mainly used in steel rolling mills of steel manufacturing, are usually together used with multi-row cylindrical roller bearings. The size of the spacing sleeve makes the roller bearing box cover screw tight, and the bearing does not need a special spring to adjust.



The bidirectional thrust tapered roller bearings are usually on the roll neck and roll bearing box to fit installation. Most of the shaft bearing seats with one or two positioning slots that you might use embedded locating slot key or similar method to prevent rotation of the housing washes.



SUNBEARING can provide professional consults to customers for your application fields and offer you specific application solutions with high efficiency and precise cost control.




Feature


The mode of this bearing is equal to SKF350980C&FAG528974


This bearing with planar shaft washers


Be able to bear slightly eccentric shaft relative to bearing box hole


There is a spacer sleeve between the two housing washer


It can withstand high axial load and can position the axial radial position to some extent
